The 2A-130G VGA EDID Emulator is designed for ATEN KVM extender or video extender installations that do not utilize a local monitor at the site where the computer/video source is located. The 2A-130G emulates and stores a default ATEN EDID (Extended Display Identification Information) setting in a non-volatile memory. This means the computer/video source can still "see" the display, even though it is not directly connected.
The 2A-130G is suitable for any ATEN KVM or video extender installation where a monitor is not required at the local site, providing a simple, cost-saving, and convenient solution for display-related boot-up problems.
The 2A-130G is suitable for any ATEN KVM or video extender installation where a monitor is not required at the local site, providing a simple, cost-saving, and convenient solution for display-related boot-up problems.
Connector 2
- VGA (D-Sub)
Maximum Refresh Rate
- 60 Hz
Supported Graphics Resolutions
- 1366 x 768, 1920 x 1200 (WUXGA)
Maximum Resolution
- 1920 x 1200 pixels
Storage temperature (T-T)
- -20 - 60 °C
Operating relative humidity (H-H)
- 0 - 80%
Operating temperature (T-T)
- 0 - 50 °C
Package weight
- 52 g
Connector 2 form factor
- Straight
Connector 1 form factor
- Straight
Connector 2 gender
- Male
Connector 1 gender
- Male
Connector 1
- USB Type-A
Cable length
- 0.35 m
Weight
- 40 g
Depth
- 65.9 mm
Width
- 34 mm
Height
- 16 mm
Harmonized System (HS) code
- 84733080
Package height
- 20 mm
Package depth
- 245 mm
Package width
- 205 mm
Product colour
- Blue, Silver
Brand
- ATEN
